Crestview Single Monitor Arm by UPLIFT Desk

SKU: MON031
$119
Float your monitor above your desktop and free up space
$119

Ships same business day if ordered by 3pm Central Time

Overview

Crestview Single Monitor Arm Features

  • Crestview is available in 3 configurations: Single (the model shown in this page), Dual, and Align Dual
  • Place your monitor at an ergonomically correct distance from your eyes (fingertip reach) and height (top of screen, just below eye level)
  • Float monitor above desktop; Reclaim uninterrupted desktop surface for objects underneath the monitor within the primary reach zone
  • Pivot a complete 360 degrees or engage the 180 degree stopping feature to prevent the arm from rotating past the back of the desk
  • Integrated wire management to keep your workspace looking tidy
  • Convenient tool holder provides a home for the included allen wrenches for future adjustments
  • Vertical adjustment range of 13"; an internal gas spring delivers a smooth, counterbalanced motion
  • Two mounting methods and hardware included:
    • Clamp-On (works with 0.4" - 3.3" desktop thickness)
    • Bolt-Through (works with 0.4" - 1.8" desktop thickness)
  • Quick release VESA plate accommodates standard 75 mm and 100 mm VESA mounting patterns
  • Supports a wide range of monitors weighing from 2.2 lb to 33 lb and up to 35" in size when measured diagonally
Crestview Single Monitor Arm clamped to a 60x30 Bamboo UPLIFT Standing Desk

Black Crestview Monitor Arm with a 60x30" Bamboo V2 Standing Desk

An infographic that shows you how to ergonomically position your monitor with the help of a monitor arm

Your Neck & Eyes Will Thank You!

The Crestview Single Monitor Arm enables a monitor to be ergonomically positioned for increased comfort and productivity while working. Adjust the height, tilt, distance, and alignment of screens to reduce stress on the neck, shoulders, and torso—and to keep eyes from straining to see a monitor that is too far away.

Distance: Place your monitor screen roughly an arm's length (fingertip reach) away. Positioning the screen too far away will cause you to have trouble seeing the monitor and your eyes will pull your head forward causing you to extend your neck; this often leads to neck, back, and shoulder discomfort.

Height: Make sure that the top line of your monitor is at or just below eye level. Tilting your head backward to read your screen leads to discomfort.

Angle: Adjust screen angle to minimize glare from windows and other light sources.

Read more on the How to Position Your Screen Ergonomically Using a Monitor Arm (pdf).

Details

UPLIFT Monitor Comparison Chart
UPLIFT Monitor Comparison Chart

Float Your Screen To Gain Space

The Crestview Monitor Arm has 13" of vertical adjustment range provided by a smooth operating gas assisted spring arm that counterbalances monitors perfectly. By floating the monitor above the desktop, valuable desktop real estate is reclaimed. More usable workspace contributes to enhanced productivity and comfort.

Primary Zone: Stretching approximately 15" to 17" from the user, this zone is used for items that are used most often (like a keyboard and mouse).

Secondary Zone: This zone stretches approximately 27" inches away from the user. The user can reach items in this zone without leaning. It's a good space for a phone, coffee cup, water bottle, reference notebooks, or calculator.

Tertiary Zone: The third zone stretches 42" to 45" from the user. It's a good space for lamps, sunglasses, or books.

An overhead image of an UPLIFT Desk with a Crestview Single Monitor Arm that illustrates all three workspace zones
Monitor cables routed through the integrated cable management channels of a Crestview Single Monitor Arm

Integrated Cable Channels and Allen Wrench Holder

Innovative Design Features

180 or 360 Degrees of Pivot: The Crestview Monitor Arm is capable of switching between 360 and 180 degrees of pivot depending on your needs. Simply engage the 180 degree stopping mechanism to prevent the monitor arm from rotating past the back edge of the desk. It prevents collisions with walls, privacy panels, or perhaps the monitors of a coworker seated opposite.

Integrated Cable Management: Ensures cables and cords are routed efficiently from the monitor to the computer. Provides a clean and organized aesthetic.

Built-in Allen Wrench Holder: Holds the included allen wrenches for minor arm adjustments. Also handy if relocating the monitor arm in the future. Holder is conveniently located behind the monitor arm base.

Upgraded Capabilities

The optional Crestview Monitor Arm Wiring Kit adds two 3.0 USB ports and two multimedia ports. Provides convenient access to USB charging, microphone and headset jacks. Cable length is 6' and is sufficient for most configurations for the wiring from the monitor arm base to the computer (cable extensions can be utilized if 6' is not enough). The Wiring Kit only comes in black, regardless of the color of monitor arm selected.

The optional Laptop Mount is ideal for laptop screen positioning. It adds all the same benefits of the monitor arm to a laptop screen (positions the top of laptop screen at eye height; positions screen at fingertip distance from the eyes). The laptop is supported by the Laptop Mount's steel tray and securely held in place with a front lip, non-slip pads on the tray, and elastic straps. A ventilation cut out on the laptop platform allows airflow to the laptop.

A close-up of two USB 3.0 ports and two multimedia ports on the base of a Crestview Single Monitor Arm
Quick Release VESA Plates for easy monitor installation

Installation & Assembly

Choose from two included mounting options:

  • The Clamp-On method clamps the monitor arm to the edge of the desktop. The clamp-on method works with desktops ranging from 0.4" - 3.3" in thickness.
  • The Bolt-Through method attaches the monitor arm anywhere on the desktop or table using an existing hole (such as a grommet hole) or a new bolt hole. The bolt-through method works with desktops ranging from 0.4" - 1.8" in thickness.

The quick release VESA plate greatly assists with monitor installation. Instead of holding the monitor up to the monitor arm to fasten with screws, attach the VESA plate to your monitor first, and then slide the VESA plate onto the monitor arm.

The Crestview Monitor Arm supports monitors weighing between 2.2 lb to 33 lb, delivering an extremely wide weight range to accommodate most monitors.

Videos



Warranty + Returns



Instructions

Specs

Specifications

Height Range (low, high) 10"-23" high measured from the desk surface to the center of the monitor mount
Vertical Height Adjustment 13" total height difference from the low to the high
Weight Capacity 2.2 - 33 lb. This will accommodate the vast majority of monitors.
VESA Compatibility Standard 75 mm and 100 mm quick release VESA plate
Mount & Desk Thickness Compatibility Clamp-On (0.4" - 3.3" desktop thickness)
Bolt-Through (0.4" - 1.8" desktop thickness)
The hardware for both mounting methods is included.
Bolt-through hole diameter 0.4" - 3.1"
Height Adjustment Mechanism Type Gas Spring
Forward Reach 23.46" from the center of the post to the VESA plate with the monitor extended directly out towards the front of the desk.
Side Extension 20.71" from the center of the post to the center of the VESA plate with the monitor extended directly out to the left or right.
Collapsible 4.6" from the back of the monitor arm to the front, with the monitor arm completely minimized.
Swivel of Arm at Base 360 or 180 degrees
Engage the stopping pin to prevent the monitor arm from pivoting more than 180 degrees.
Monitor Tilt Range 90 (+/-45) degrees
Monitor Pan Range 180 (+/-90) degrees
Monitor Rotation 180 (+/-90) degrees
Shipping Box Dimensions & Weight 22.1" L x 10" W x 4.3" H, 13.6 lb
Monitor Arm Weight With Clamp: 11.2 lb
With Bolt-Through: 9.1 lb
Monitor Arm Weight BIFMA x5.5 2014 for Desk Products

FAQ

Frequently Asked Questions

  1. Can I use this arm with a desk that isn't an UPLIFT Desk?

    Yes, this accessory is compatible with UPLIFT and non-UPLIFT desks, as long as the desktop meets the thickness specification:

    • Clamp-On (0.4" - 3.3" desktop thickness)
    • Bolt-Through (0.4" - 1.8" desktop thickness)
  2. Do you have the Crestview in a dual monitor arm version?

    Yes, the Crestview Dual Monitor Arm has the same features and a similar range of adjustability.

    The width limit for a dual monitor arm is not unlimited like the Crestview Single Monitor Arm. If you have extremely wide monitors, you can use two Crestview Single Monitor Arms. This enables you to place the bases far enough apart to accommodate wide screens and still maintain adjustability.

  3. What is a "quick-release VESA mount"?

    We understand the frustration of holding a monitor up with one hand while trying to fasten it onto the VESA plate with the other.

    The quick release VESA mount makes attaching a monitor simple. Fasten the included VESA plate to the back of your monitor, then slide the VESA plate into the mount at the end of the monitor arm.

    This feature also makes changing or moving monitors much easier. Press on the tab to disengage the lock and slide it off the monitor arm.

  4. Can the monitor arms be locked, so that the monitor does not move if bumped?

    The base should not move if installed properly but there is no way to lock the swivel of the arm joints. The monitor tilt adjustment can be tightened so that the angle will not change if bumped.

  5. I need help setting up my monitor arm at the ergonomically correct position. Do you have any tips?

    Distance: Place your monitor screen roughly an arm's length (fingertip reach) away. Positioning the screen too far away will cause you to have trouble seeing the monitor and your eyes will pull your head forward causing you to extend your neck; this often leads to neck, back, and shoulder discomfort.

    Height: Make sure that the top line of your monitor is at or just below eye level. Tilting your head backward to read your screen leads to discomfort.

    Angle: Adjust screen angle to minimize glare from windows and light sources

    Read more on the How to Position Your Screen Ergonomically Using a Monitor Arm (pdf).

Crestview Single Monitor Arm



Why Buy?

Position your monitor at exactly the right height and distance to prevent eye strain and neck movement. Also reclaim valuable desk space by floating your monitor.

Features & Specs

  • Holds monitors from 2.2 lb - 33 lb
  • 13" of vertical height adjustment
  • Two Included Mounting Options
  • Clamp-On (works with 0.4" - 3.3" desktop thickness)
  • Bolt-Through (works with 0.4" - 1.8" desktop thickness)
  • 360 degree or activate the 180 degree arm rotation
  • Quick-release standard VESA mount (75 mm and 100 mm)
  • Integrated Cable Management Channels
  • Built-In Allen Wrench Holder
  • Optional Crestview Monitor Arm Wiring Kit adds two 3.0 A USB ports and two multimedia ports. Cables are 6' long
  • Optional Laptop Mount to hold a laptop instead of a monitor
two uplift crestview single monitor arms





Why Buy?

Two Crestview Single Monitor Arms provide a wider range of motion for your dual monitor setup than the Crestview Dual Monitor Arm. Position your monitor at exactly the right height and distance to prevent eye strain and neck movement. Also reclaim valuable desk space by floating your monitor.

Features & Specs

  • Holds monitors from 2.2 lb - 33 lb
  • 13" of vertical height adjustment
  • Two Included Mounting Options:
  • Clamp-On (works with 0.4" - 3.3" desktop thickness)
  • Bolt-Through (works with 0.4" - 1.8" desktop thickness)
  • 360 degree or activate the 180 degree arm rotation
  • Quick-release standard VESA mount (75 mm and 100 mm)
  • Integrated Cable Management Channels
  • Built-In Allen Wrench Holder
  • Optional Crestview Monitor Arm Wiring Kit adds two 3.0 A USB ports and two multimedia ports. Cables are 6' long
  • Optional Laptop Mount to hold a laptop instead of a monitor
uplift crestview single monitor arm

Crestview Monitor Arm Wiring Kit



Why Buy?

Add convenient charging, data transmission, mic and headset use to your monitor arm.

Only available with Crestview monitor arms.

Features & Specs

  • Two 3.0 USB ports
  • Two multimedia ports
  • Cables are 6' long and connect to your computer
uplift crestview wiring kit

UPLIFT Desk Warranty Policy

We stand firmly behind the quality of our products. All UPLIFT Desk products come with a 15 Year Warranty, visit the Warranty page for this particular product's warranty policy.

Return Policy

Free Returns with Free Return Shipping within 30 days, visit our Returns page for the full policy.
