Crestview Dual Monitor Arm by UPLIFT Desk

SKU: MON032
Was:
$179
Float your monitors above your desktop and free up space
Was:
$179

Ships same business day if ordered by 3pm Central



Overview

Crestview Dual Monitor Arm Features

  • Crestview is available in 4 configurations: Single, Dual (the model shown on this page), Align Dual, Align Triple
  • Ergonomically position two monitors at approximately fingertip reach to the screen, with the top of the monitor at about eye level
  • Float monitors above desktop surface; Reclaim continuous desktop surface for objects underneath the two monitors within the primary reach zone
  • Integrated wire management to keep your workspace looking tidy
  • Convenient tool holder provides a home for the included allen wrenches for future adjustments
  • Vertical adjustment range of 13"; an internal gas spring delivers a smooth, counterbalanced motion
  • Two mounting methods and hardware included:
    • Clamp-On (works with 0.4" - 3.3" desktop thickness)
    • Bolt-Through (works with 0.4" - 1.8" desktop thickness)
  • Quick release VESA plate accommodates standard 75 mm and 100 mm VESA mounting patterns
  • Supports a wide range of monitors weighing from 2.2 lb to 33 lb and up to 35" in size when measured diagonally
  • 15 year warranty - all UPLIFT Desk products include a 15 year warranty
Crestview Dual Monitor Holder mounted to a height adjustable sit-stand desk

Black Crestview Dual Monitor Arm mounted on a 60x30" Walnut Solid Wood V2 Standing Desk



Details

An infographic that shows you how to ergonomically position your monitor with the help of a monitor arm

Perfect Positioning For Your Neck & Eyes

The Crestview Dual Monitor Arm enables two monitors to be ergonomically positioned for increased productivity and comfort. Adjust the distance, alignment, height, and tilt of monitors to reduce stress on the shoulders, torso, and neck—and to reduce eye strain from monitors that are too far away.

Height: Make sure that the top line of your monitors are at or just below eye level. Tilting your head backward to read your screen leads to discomfort.

Distance: Place your monitor screens roughly an arm's length (fingertip reach) away. Positioning the screens too far away will cause you to have trouble seeing the monitors and your eyes will pull your head forward causing you to extend your neck; this often leads to neck, back, and shoulder discomfort.

Vertical Angle: Adjust the vertical screen angle to minimize glare from windows and other light sources.

Horizontal Angle: For the monitors that are positioned not directly in front of you, adjust the horizontal angle so that they're more perpendicular to your perspective and less parallel to your desk.

Read more on the How to Position Your Screen Ergonomically Using a Monitor Arm (pdf).

Gain Space with Floating Monitors

The Crestview Dual Monitor Arm has 13" of vertical adjustment range provided by a smooth operating gas assisted spring arm that counterbalances monitors perfectly. Valuable desktop real estate is reclaimed by floating the two monitors above the desktop. More usable desktop space contributes to enhanced comfort and productivity.

Primary Zone: Approximately 15" to 17" from the user, this zone is the most valuable and is used for items that are used most frequently, like a keyboard and mouse.

Secondary Zone: Approximately 27" inches away from the user. The user can reach items within this zone without the need to lean. It's a good space for a coffee cup, water bottle, phone, calculator, or reference notebooks.

Tertiary Zone: Approximately 42" to 45" from the user. It's a good space for sunglasses, books, or lamps.

Recoup desktop space with monitor arms by floating your monitors above the desktop
A close-up of monitor cables routed through the integrated cable management channels of a Crestview Dual Monitor Arm

Integrated Cable Channels and Allen Wrench Holder

Convenient Design Features

Integrated Allen Wrench Holder: Holder is conveniently located behind the monitor arm base and holds the included allen wrenches for adjustments or for future monitor arm relocation.

Built-in Cable Management: Ensures cables and cords are routed efficiently from the monitor to the computer. Provides a clean and organized aesthetic.

Upgraded Monitor Arm Capabilities

The optional Crestview Monitor Arm Wiring Kit adds two multimedia ports and two 3.0 USB ports. This kit adds convenient access to microphone and headset jacks and USB connectivity. The kit's cable length is 6' and most users find this to be a sufficient length for the wiring from their computer to the monitor arm base. If more cable length is needed, cable extensions can be utilized. The Wiring Kit only comes in black, regardless of the color of monitor arm selected.

The optional Laptop Mount is ideal for laptop screen positioning. It provides all the same benefits of the monitor arm to a laptop screen (positions the top of screen at eye height; positions laptop screen at fingertip distance from the eyes). The laptop is supported by a steel tray and held in place securely with a front lip, non-slip pads on the tray, and included elastic straps. Airflow is provided to the laptop fans via a ventilation cut out on the laptop platform.

A close-up of two USB 3.0 ports and two multimedia ports on the base of a Crestview Dual Monitor Arm
Quick Release VESA Plates for monitor installation

Quick Release VESA Plates

Assembly & Installation

Choose from two included mounting options:

  • The Clamp-On mount attaches the monitor arm along the edge of the desktop. The clamp mount works with desktops that are 0.4" to 3.3" thick.
  • The Bolt-Through mount positions the monitor arm anywhere on the desktop using an existing hole, like a grommet, or an entirely new hole. The bolt-through mount works on desktops between 0.4" to 1.8" thick.

Each arm of the Crestview Dual Monitor Arm supports monitors weighing from 2.2 lb to 33 lb, meaning just about any monitor is compatible.

Quick release VESA plates assist immensely with monitor installation. This takes out the difficult challenge of needing to hold a monitor up to the monitor arm to fasten with screws. Instead: attach the VESA plates to the monitors, then slide the VESA plates onto each monitor arm.



Videos




Warranty + Returns




Assembly



Specs

Weight Capacity 2.2 - 33 lb per arm. This will accommodate the vast majority of monitors.
VESA Compatibility Included standard 75 mm and 100 mm quick release VESA plate
Mount & Desk Thickness Compatibility Clamp-On (0.4" - 3.3" desktop thickness)
Bolt-Through (0.4" - 1.8" desktop thickness
The hardware for both mounting methods is inclued.
Bolt-through hole diameter One hole: 2.2" - 3.1"
Two holes: 0.4" - 1.3" each, spaced 1.7" apart
Height range (low, high) 10"-23" high measured from the desk surface to the center of the monitor mount.
Vertical Height Adjustment 13" total height difference from the low to the high.
Height Adjustment Mechanism Type Gas Spring
Forward Reach 23.5" from the center of the post to the VESA plate with the monitor extended directly out towards the front of the desk.
Side Extension 22.2" from the center of the post to the center of the VESA plate with the monitor extended directly out to the left or right.
Collapsible 4.6" from the back of the monitor arm to the front, with the monitor arm completely minimized.
Swivel of Arm at Base 270 degrees
Monitor Tilt Range 90 (+/-45) degrees
Monitor Pan Range 180 (+/-90) degrees
Monitor Rotation 180 (+/-90) degrees
Shipping Box Dimensions & Weight 25.4" L x 14" W x 4.7" H, 21.4 lb
Monitor Arm Weight With Clamp: 18.1 lb
With Both-Through: 16.1 lb
Testing BIFMA x5.5 2014 for Desk Products


FAQ

Frequently Asked Questions

  1. Can I use this arm with a desk that isn't an UPLIFT Desk?

    Yes, this accessory is compatible with UPLIFT and non-UPLIFT desks, as long as the desktop meets the thickness specification:

    • Clamp-On (0.4" - 3.3" desktop thickness)
    • Bolt-Through (0.4" - 1.8" desktop thickness)
  2. Do you have the Crestview in a single monitor arm version?

    Yes, the Crestview Single Monitor Arm has the same features and a similar range of adjustability, and a larger width limit compared to the Crestview Dual Monitor Arm.

    If you have extremely wide monitors, you can use two or more Crestview Single Monitor Arms. This enables you to place the monitor arm bases far enough apart to accommodate wide screens and still maintain adjustability.

  3. What is a "quick-release VESA mount"?

    We understand the frustration of holding a monitor up with one hand while trying to fasten it onto the VESA plate with the other.

    The quick release VESA mount makes attaching a monitor simple. Fasten the included VESA plate to the back of your monitor, then slide the VESA plate into the mount at the end of the monitor arm.

    This feature also makes changing or moving monitors much easier. Press on the tab to disengage the lock and slide it off the monitor arm.

  4. Can the monitor arms be locked, so that the monitor does not move if bumped?

    The base should not move if installed properly but there is no way to lock the swivel of the arm joints. The monitor tilt adjustment can be tightened so that the angle will not change if bumped.

  5. Does the Crestview Dual Arm have a stop feature so the arm cannot rotate past the back edge of my desk?

    No, the Crestview Dual Monitor Arm can rotate past the back edge of the desk. This is because with two arms, the monitors would not be able to be pushed far enough back to achieve an ergonomic position for most users if the arms’ elbows could not extend past the back edge of the desk.

  6. I need help setting up my monitor arm at the ergonomically correct position. Do you have any tips?

    Distance: Place your monitor screen roughly an arm's length (fingertip reach) away. Positioning the screen too far away will cause you to have trouble seeing the monitor and your eyes will pull your head forward causing you to extend your neck; this often leads to neck, back, and shoulder discomfort.

    Height: Make sure that the top line of your monitor is at or just below eye level. Tilting your head backward to read your screen leads to discomfort.

    Angle: Adjust screen angle to minimize glare from window and light sources.

    Read more on the How to Position Your Screen Ergonomically Using a Monitor Arm (pdf).

Crestview Dual Monitor Arm

+$139

Why Buy?

Position your dual monitors at exactly the right height and distance to prevent eye strain and neck movement. Also reclaim valuable desk space by floating your monitors.

Features & Specs

  • Holds two monitors from 2.2 lb - 33 lb each
  • 13" of vertical height adjustment
  • Two Included Mounting Options:
    • Clamp-On (works with 0.4" - 3.3" desktop thickness)
    • Bolt-Through (works with 0.4" - 1.8" desktop thickness)
  • Quick-release standard VESA mount (75 mm and 100mm)
  • Integrated Cable Management Channels
  • Built-In Allen Wrench Holder
  • Optional Crestview Monitor Arm Wiring Kit adds two 3.0 USB ports and two multimedia ports. Cables are 6' long
  • Optional Laptop Mount to hold a laptop instead of a monitor
UPLIFT Desk Crestview Dual Monitor Arm

Videos

UPLIFT Desk Warranty Policy

We stand firmly behind the quality of our products. All UPLIFT Desk products come with a 15 Year Warranty, visit the Warranty page for the full policy.

Return Policy

Free Returns with Free Return Shipping within 30 days, visit the Returns page for the full policy.

Reviews

Compare

Crestview Dual Monitor Arm

MON032

Shop Now >
Slim, attractive design (ideal if rear of monitor is visible) Dual long reach USB Kit add-on option Holds lighter/heavier monitors USB Kit add-on option Move and keep monitors in line with one motion Elegant, modern design with spring tension indicator
Weight capacity: 4.4 to 11 lb per arm Weight capacity: 4.5 to 17.5 lb per arm Weight capacity: 2.2 to 33 lb per arm Weight capacity: 2.2 to 17.6 lb per arm Weight capacity: 4.4 to 19.8 lb per arm
39.5" Max Monitor Size* 52" Max Monitor Size* 35" Max Monitor Size* 32" Max Monitor Size* 32" Max Monitor Size*
Clamp mount: Compatible with 0.75" to 3.75" thick desktops
Bolt-through mount: Compatible with 0.6" to 2.1" thick desktops
Clamp mount: Compatible with 0.75" to 3.75" thick desktops
Bolt-through mount: Compatible with 0.6" - 2.13" thick desktops
Clamp mount: Compatible with 0.4" to 3.3" thick desktops
Bolt-through mount: Compatible with 0.4 to 1.8" thick desktops
Clamp mount: Compatible with 0.4" to 3.3" thick desktops
Bolt-through mount: Compatible with 0.4 to 1.8" thick desktops
Clamp mount: Compatible with 0.4" to 3.3" thick desktops
Bolt-through mount: Compatible with 0.4 to 3.1" thick desktops
VESA compatibility: 75mm and 100mm Quick Release VESA compatibility: 75mm and 100mm Quick Release VESA compatibility: 75mm and 100mm Quick Release VESA compatibility: 75mm and 100mm Quick Release VESA compatibility: 75mm and 100mm Quick Release
